- Brand: Intel
- Model Number: BX80684I38100
- Processor Family: Intel Core i3
- CPU Speed: 3.60 GHz
- Number of Cores: 4
- 8th Generation Intel Core i3 Processors
- Code Name: Coffee Lake
- Vertical Segment: Desktop
- Processor Number: i3-8100
- Lithography: 14 mm
- Performance
- No. of Cores: 4
- No. of Threads: 4
- Processor Base Frequency: 3.60 GHz
- Cache: 6 MB
- Bus Speed:
- 8 GT/s DMI3
- TDP: 65 W
- Supplemental Information
- Embedded Options Available: No
- Conflict Free: Yes
- Memory Specifications
- Max Memory Size (dependent on memory type): 64 GB
- Memory Types: DDR4-2400
- Max No. of Memory Channels: 2
- ECC Memory Supported: No
- Graphics Specifications
- Processor Graphics
- Intel UHD Graphics 630
- Graphics Base Frequency: 350 MHz
- Graphics Max Dynamic Frequency: 1.10 GHz
- Graphics Video Max Memory: 64 GB
- Execution Units: 23
- 4K Support: Yes, at 60Hz
- Max Resolution (HDMI 1.4)
- 4096x2304@24Hz
- Max Resolution (DP)
- 4096x2304@60Hz
- Max Resolution (eDP - Integrated Flat Panel)
- 4096x2304@60Hz
- DirectX* Support: 12
- OpenGL* Support: 4.5
- Intel Quick Sync Video: Yes
- Intel InTru 3D Technology: Yes
- Intel Clear Video HD Technology: Yes
- Intel Clear Video Technology: Yes
- No. of Displays Supported: 3
- Device ID: 0x3E91
- Expansion Options: Scalability 1S Only
- PCI Express Revision: 3
- PCI Express Configurations
- Up to 1x16 or 2x8 or 1x8+2x4
- Max No. of PCI Express Lanes: 16
- Package Specifications
- Sockets Supported: FCLGA1151
- Max CPU Configuration: 1
- Thermal Solution Specification: PCG 2015C (65W)
- TJUNCTION: 100°C
- Package Size: 37.5mm x 37.5mm
- Advanced Technologies
- Intel Optane Memory Supported: Yes
- Intel Turbo Boost Technology: No
- Intel vPro Technology: No
- Intel Hyper-Threading Technology: No
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel TSX-NI: No
- Intel 64: Yes
- Instruction Set: 64-bit
- Instruction Set Extensions: SSE4.1/4.2, AVX2
- Idle States: Yes
- Enhanced Intel SpeedStep Technology: Yes
- Thermal Monitoring Technologies: Yes
- Intel Identity Protection Technology: Yes
- table Image Platform Program (SIPP)
- No
- Security & Reliability
- Intel AES New Instructions
- Yes
- Secure Key
- Yes
- Intel Software Guard Extensions (Intel SGX)
- Yes
- Intel Memory Protection Extensions (Intel MPX)
- Yes
- Intel OS Guard
- Yes
- Intel Trusted Execution Technology
- No
- Execute Disable Bit
- Yes
- Intel Boot Guard
- Yes
