FEATURES:

• Scratch Proof optical sensor
• High resolution 600 dpi optical sensing
• Fingerprint/Pin/Card authentication
• 360° verification angle
• 2.8" TFT Color screen
• TCP-IP network connectivity
• USB connectivity for communication and data backup
• High performance sensing with <1s identification time
• Inbuilt access control functionality
• Inbuilt battery backup
• SSR report in excel forms

TECHNICAL SPECIFICATIONS:

• CPU 32 bit Microprocessor
• Memory 64M RAM, 256M Flash
• Sensor Scratch proof High performance optical sensor
• DPI rating 600 dpi resolution
• Sensor area 16mm x 14mm
• OS Embedded Linux OS
• Operation mode Offline / Online
• Display 2.8" TFT Color screen
• Keypad Alpha-numeric backlit keypad
• Indicators Audio visual indication , with dual color LEDs
• Fingerprint templates 1000 users
• Card Ids 1000 users
• Transaction capacity 80000 logs
• Verification angle 360° verification angle
• FAR < 0.0001%
• FRR < 1%
• Verification time < 0.5s
• Algorithm Advanced Smart finger algorithm V 15.0
• Authentication modes Fingerprint only/ Fingerprint + PIN/ Fingerprint + EM Card
• Backup Battery Inbuilt battery backup
• Real time Clock Supported
• Voice notification Supported
• Card Reader Inbuilt 125 Khz EM card reader
• Languages Multi-language support
• Card Reader Range 3-5 cms read range
• Door bell function Supported
• Access control support Door Relay Access control function with NO-NC support
• Ethernet TCP/IP 10/100 ethernet interface
• USB USB 2.0 for communication and data backup
• Power requirement DC 12V, 1.5A
• Operation temperature 0°-45°C
• Operating Humidity up to 90% (non condensing)
• Construction material ABS plastic
• Dimensions 184mm x 136mm x 37.6mm
• Certifications CE, FCC, ROHS
